5 Port Industrial Gigabit Ethernet Switch

share
WeChat
Sina Weibo
QQ
copy Link
Facebook
X
LinkedIn
Brand CENTROPOWER
Model Net-S1605-4G-I
Color Dark purple
0755-23200933
DetailFile

5 Port Industrial Gigabit Ethernet Switch


Description：

Entry-level 5-port industrial Ethernet switch supporting IEEE802.3/802.3u/802.3ab. With 1000Mbps, full duplex, MDI/MDIX adaptiveRJ45 port. The switch has an operating temperature of -40 to 70 °C, can adapt to a variety of harsh environments, and can be easily placed in a compact control box. Wall-mounted mounting features, wide temperature operation and IP30-rated enclosures and LED indicators make the industrial switch a plug-and-play industrial grade device that is a reliable solutionfor your industrial automation networking.

Features：

  • Follow IEEE802.3, IEEE 802.3u, Ethernet standard

  • Provide 5 10/100/1000Mbps-RJ-45 ports

  • Backplane bandwidth 10Gbps

  • Support IEEE802.3x flow control

Specifications:

ItemDescription
Port

5 10/100Base-TX RJ-45

LED Indicator

Power(yellow),Data indicator（ Link/Act Green） .

Input voltage

9~24VDC (switch)

Power consumption5W Suggested the use of power adapterPower: ≥10W
Operating temperature

0 ~45℃

storage temperature-10 ~60 ℃
Working humidity

0% ~85% (No condensation)

Cooling

Natural cooling

Backplane bandwidth10G
MAC address table

2K

Flow control protocolIEEE 802.3x full-duplex flow control.









Q1: Are you a factory?
A: Yes, we are a POE Switches & Power Supply factory.
Q2: How many years is your products warranty?
A: Regular 1 year.
Q3: Do you accept OEM?
A: Sure, we accept OEM.
Q4: What is your delivery time and payment term?
A: We will reply the specific delivery time according to your order qty. Usually 7~10days. We accept T/T, Paypal and Western Union payment method.
Q5: Do you have any certification?
A: Yes, we have UL, FCC, CE, RoHS right now. If you need other certifications in large quantities order, we can apply it for you.
