8GE AI Multifunction PoE Switch
share
- AI Multifunction PoE Switch, Unmanaged
- PoE Port: 8 10/100/1000Mbps RJ45 Port
- 4DIP: AI PoE Watchdog, VLAN, Extend, QOS
- AI PoE Watchdog: 24hour AI detection
- VLAN: PoE port are isolated from each other
- Extend: PoE port extend to 250meters
- QOS: 2 PoE ports to set the priority
- Support IEEE 802.3af/at, Single Port Max.30W
- With 125W Power Adaptor (Input 100-240VAC)
- Enclosure size: 138mm*79mm*25mm
- 4KV port surge
- PoE Port: 8 10/100/1000Mbps RJ45 Port
- 4DIP: AI PoE Watchdog, VLAN, Extend, QOS
- AI PoE Watchdog: 24hour AI detection
- VLAN: PoE port are isolated from each other
- Extend: PoE port extend to 250meters
- QOS: 2 PoE ports to set the priority
- Support IEEE 802.3af/at, Single Port Max.30W
- With 125W Power Adaptor (Input 100-240VAC)
- Enclosure size: 138mm*79mm*25mm
- 4KV port surge
DetailSpecificationsDownloads
8GE AI Multifunction PoE Switch
Description:
The 8 Port /8 PoE Ethernet Switch is fully integrated to support security monitoring,provides fast packet forwarding capability, as well as
Gigabit Ethernet transfer rates byutilizing the appropriate bandwidth to ensure clear images/smooth transmission andenough bandwidth
for high-definition video.
Features:
Conforms toIEEE802.3,IEEE 802.3u,IEEE802.3af,IEEE802.3at
Provides 8 10/100/1000Base-T ports
Provides 8 PoE injector and 120W power adapter
High back-plane bandwidth 16Gbps
IEEE802.3x Flow control
Specifications:
| Item | Description | |
| Power | Power supply | External Power Adaptor |
| Voltage Range | DC48-57V | |
| Switch Consumption | <5W | |
| Ethernet | Speed | 1-8 Port: 10/100/1000Mbps |
| Transmission Distanc | 100Meter (328ft) | |
| Network Switch | Ethernet Standard | IEEE 802.3x/IEEE 802.3/802.3u/802.3ab/802.3af/at |
| Switching capacity | 16G | |
| Transfer Rate | 14,880pps for 10Mbps | |
| 148,800pps for 100Mbps | ||
| 148,8000pps for 1000Mbps | ||
| MAC Address | 4K MAC address table | |
| LINK/ACT | On-Green | The port is connecting |
| Blinks-- | The port is receiving or transmitting data | |
| Off-- | The port is not linked successfully with the device | |
| POE | On-Green | PD is connected |
| Off-- | No PD is connected or power forwarding fails | |
| Capacity | 115W | |
| PoE pin assignmnet | V+(RJ45 Pin 1,2), V-(RJ45 Pin 3,6) | |
| Environment | Working Temperature | 0-40℃ |
| Storage Temperature | -40-70℃ | |
| Humidity Non condesing | 0~90% | |
| Mechanical | Dimension | 138 x 79 x 25mm |
| Color | Black | |
