8 Port Ethernet Switch
8 Port Ethernet Switch
Net-1008-8E
Description：
The Network Switch is g custom mode 10M/100M Ethernet Switch. This device issuitable for network data exchange transmission soeciclizeofor,the switch is equipped with 8 ports ,The product utlizes professional chips to increaseoackplane bandwidth andbuffer parameters,The product adopts an industrial design and utlizes fanless heat dissipation,making mainten-ance efficientand wiring reasonable.
Features：
In accordance withIEEE 802,3i,IEEE 802.3u,IEEE802.3ab
Supports port auto MDl/MDIX
Supports Monitor Mode and Network Mode switching
All ports support line speed switching and jumbo frame transmission
Zero configuration feature, automatically supplies power to adapted devices
Panelindicator lights monitor working states and help troubleshooting
Specifications:
| Item | Description |
| Power Indicator Light | Red Light on：Normal Off：Not Powered Green Light On：Normal connection equipment Port Light Flashing：Normalcommunication Port Light Blinking:evice no network connection |
| Fixed Port | 8 Port 10/100Mbps/RJ45 |
| Internet Protocol | IEEE 802.3I/IEEE 802.3X/IEEE802.3U/IEEE802.3ab/IEEE802.1q |
| Package Forwarding Rate | 10M Port max 14880pps 100M port max 148800pps |
| Lightning Series | 2KV |
| Input voltage | DC 5V |
| Wattage | 4W |
| Working Temperature | 0°C-40℃ |
| Working Humidity | 10%-90% Non-condensation |
| Heat Dissipation | Natural Dissipation |
Net-1608-8P
Description：
It is a high performance 8 port 10/100/1000Mbps Ethernet switch, it provides one full wire-speed gigabit networking connection to your working group or server ,play and plug ,this flexible non-blocking frame make user not subject to the limit of bandwidth and media network. It support halfduplex flow control and full-duplex back pressure ,each port support auto-adaptive function, provide an economical, practical, high cost-effective sharing device for broadband LAN .adopting store-and-forward mode ,can effectively isolate broadcast storm ,reduction error /wrong package, avoiding network congestion and network conflict .LED panel can detect the condition of each port and whole system.
Features：
Comply with IEEE802.3,IEEE802.3u and 802.3ab sandard.
8 10/100/1000Mbps auto-adaptive RJ45,support AutoMDI/MDIX.
Support 4K MAC address
Support IEEE 802.3x half-duplex and full-duplex back pressure mode.
Non-blocking exchange frame, full wire-speed transmission and max throughput filter the data packet.
Support MAC address, auto-adjust transmission mode and max throughput filter the data packet.
Support MAC address, auto-adjust transmission mode and transmission rate Mini appearance dimension design.
LED indicators, link and activity, provide the simple indication of operation status and troubleshooting.
DC5V/1A power supply Desktop metals case design.
Specifications:
| Item | Description |
| Standard | IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX fast Ethernet IEEE 802.3ab 1000Base-T gigabit Ethernet ANSI/IEEE standard 802.3 auto-adjust IEEE 802.3x flow control |
| Filter andtransmission rate | Ethernet 10Mbps (half -duplex)20Mbps (fullduplex),10Mbps:14,880pps Fast Ethernet 100Mbps(half-duplex ),200Mbps (full-duplex), 100Mbps:148800pps Gigabit Ethernet 2000Mbps (full-duplex),1000Mbps:1488000pps |
| Network Media | 10Base-T: 3UTP or higher ((≤100m) 100Base-TX: 5 UTP(≤100m) 1000Base-T: 6UTP (≤100m) |
| Port No. | 8×10/100/1000M RJ45 port |
| Uplink | all ports can act as Uplink port |
| Transmission mode | store-and -forward |
| Temperature | Operation temperature: 0~40°C (32℉~104℉) Storage temperature: -40~70°C (-40℉~158℉) |
| Humidity | Operation humidity :10%~90% ,non-condensingt Storage humidity :5%~95%,non-condensing |
| Bandwidth | 16G |
| LED indicators | one power source indicator ( green LED ) 8 data LED indicators (Link/Act: green LED) |
| Power supply | External power adapter DC 5V/1A Support DC 5-12VInput |
| Material (case) | Metal |
